| Quantity: | |
|---|---|
FA
Elite-indus
34021100
Foam Chemical Concrete Foaming Agent for Cellular Light Weight Concrete Blocks
ELITE foaming agent is a material that facilitates formation of foam such as a surfactant or a blowing agent. A surfactant, when present in small amounts, reduces surface tension of a liquid (reduces the work needed to create the foam) or increases its colloidal stability by inhibiting coalescence of bubbles.A blowing agent is a gas that forms the gaseous part of the foam.
Specifications
Parameter | Specs |
Appearance | light yellow pure transparent oily liquid |
Proportion(kg/L) | 1.06 |
PH value | 6.8-7.2 |
Content of inorganic salts | ≤0.5% |
Rate of absorption | ≥40% |
Hues (APHA) | ≤50 |
Consumption (kg/m3) | 0.35-0.45 |
Operating Temperature(°C) | ≥5 |
Safety | Stable chemistry, non-poisonous, no flavor, non-inflammable |
Use and Formula
Foam Agent:Water 1:40
Oven-Density | In | KG/m3 | 400 | 600 | 800 | 1000 | 1200 | 1400 | 1600 | 2350 Conv.concr. |
Sand | KG | - | 210 | 400 | 560 | 750 | 950 | 1100 | 1950 | |
Cement | KG | 300 | 310 | 320 | 350 | 360 | 380 | 400 | 320 |
Water in mortar | KG | 110 | 110 | 120 | 120 | 140 | 150 | 160 | 180 |
Quantity of foam | Ltrs | 800 | 715 | 630 | 560 | 460 | 370 | 290 | - |
Water in foam | KG | 64 | 57 | 50 | 45 | 37 | 30 | 23 | - |
Wet Density | KG/m3 | 474 | 687 | 890 | 1075 | 1287 | 1510 | 1683 | 2400 |
Foam Agent Use | KG | 1.5 | 1.4 | 1.2 | 1.1 | 0.9 | 0.7 | 0.6 | - |
Water/Cement Ratio | 0.58 | 0.54 | 0.53 | 0.47 | 0.49 | 0.47 | 0.46 | 0.56 | |
Max Strength in | N/mm2 | ~1 | ~2 | ~3 | ~4 | ~8 | ~12 | ~18 | 25+ |
Average Lambda | W/m x K | 0.096 | 0.18 | 0.21 | 0.32 | 0.405 | 0.45 | 0.55 | 2.10 |
(Achieved Strength at the lab with optimum sand cement qualities) More cement will increase strength. Using Lightweight aggregate in matrix of cell,concrete increases strength up to 500% in overall
densities below 1000KG/m3
50KGS/200KGS/Drum or 1000KGS/IBC TANK,16000KGS/20’gp
Advantages
1, Use high quality natural plant polymer materials
2, By complex chemical reactions generated
3, Light yellow pure transparent oily liquid
4, Not sensitive to hard water,non - toxic,tasteless,no sediment
5, PH value close to neutral,noncorrosive to cement and metal, environmental friendly
6, Easy to store,with excellent foaming performance, rich foam with moderate stability
